Setup Antenna LNB pol Angle
LNB pol angle type
Setup mode
Set pol angle menu
Antenna menu
LNB pol angle Signal
SETUP MODE ?
YES NO
1. Press LEFT arrow key to move cursor to YES and press OK key to enter SETUP mode.
+ANTENNA +SATELLITE
+SYSTEM +INSTALLATION
2. Press OK key to enter ANTENNA menu.
+MANUA L SEARCH +SET POL ANGLE
+SEARCH PARAM +SET PARAMETERS
3. Press RIGHT arrow key to move cursor to SET POL ANGLE menu and press OK key to
enter it.
SELECT POL ANGLE MENU
CALIBRATI ON
4. Press UP and DOWN arrow keys to select the LNB pol angle menu and press OK key to
run the selected operation 'CALIBRATION' or 'MANUAL ADJUST'. Select MANUAL ADJUST
to control LNB pol angle manually. If the control board, LNB pol potentiometer or belt is
replaced, select CALIBRATION to calibrate LNB pol angle.
LNB POL ANGLE SI GNAL: 180
20
5. Press UP and DOWN arrow keys to increase or decrease the LNB pol angle manually and
the correspondent SIGNAL level will be displayed next to it. Press RETURN key to return to
the main display.
NOTE: LNB POL ANGLE menu will be displayed only if MANUAL ADJUST is selected.
