- TX Mute: is a transmit inhibit output from the ACU to disable/
mute the modem transmit through a 5V (High) or 0V(LOW)
current whenever the antenna is blocked, searching, or is mis-
pointed 0.5° from peak satellite position.
- Modem Lock: is the modem lock output from the modem
provides a logic input through a 5V (High) or 0V(LOW) current
to the ACU to identify when it is on the correct satellite.
Note: TX Mute and Modem Lock items will only be activated
when the modem protocol is set as I/O Console.
4
Set Modem
Conguration
-Conrm to congure your modem settings.
To Next Page
