Intellian v130 User Manual

97
REMOTE WEB ACCESS
No. Item Description
1
Parameter Setting
Set antenna search & tracking parameters.
These parameters should only be changed by an authorized
service technician. Improper setting of these parameters will
render your system inoperable.
2
Search & Tracking
Parameter Setting
DVB Detect and Tracking Level Threshold: display/set current
detect level threshold and tracking level threshold when DVB
tracking mode is chosen to be used.
- NBD Detect and Tracking Level Threshold: display/set
current detect level threshold and tracking level threshold
when NBD tracking mode is chosen to be used.
- Enable Threshold: display/set TX enable threshold.
- Wait time: set the time-out for automatic initiation of a search
after the signal level drops below the pre-dened threshold
value.
- Search Step: set increment step size.
- Search 1 & 3 Range: set Search 1 & 3 search range. Search
is conducted in a two-axis pattern consisting of alternate
movements in azimuth and elevation as forming expanding
square.
- Search 2 Range: is reserved for future use.
3
Tilt Sensor Bias
Adjust the two solid-state tilt sensors used to provide absolute
cross-level tilt of the antenna and elevation feedback to
eliminate long-term pointing drift (error). Tilt bias is required to
be adjusted when the antenna control board or sensor box is
replaced. Check to see whether or not the bubble is located at
the center of the level vial.
4
Elevation Adjust
Adjust the angle difference between the mechanical elevation
angle and actual elevation angle.
5
Conical Range Set conical range while the antenna is on tracking mode.
6
Rate Sensor
Adjust
Calibrate DC voltage output from the three rate sensors used
to sense antenna motion in azimuth, elevation and cross-level
axes. During the calibration process, the antenna should avoid
any motion as it can affect the antenna’s performance.
7
Idle Mode
Release the elevation and cross level motor brakes while
the antenna is in SETUP mode. The antenna can be moved
manually during the idle mode.
8
Reboot Reboot the system.
