Intermec PM43 - Page 65

TITLE
Model
DOCUMENT NO.
PAGE
PM43 Service Work Instructions
PM43,PM43C
SWIPM43x-000
Page
65 of 70
Intermec Proprietary Document
Internal Rewinder Assembly Service Kit
The intend of the internal rewinder service kit and label taken spare are for retrofitting a PM43/PM43c without the internal
rewinder option installed from the factory by an authorized Intermec service partners or Intermec service depot.
Figure 7 –Service Kit 710-090S-001 Kit include this type of gear
