16 of 140
Version 2.5 (11/2020) UL
Translation of the original operating manual
Product information
3.2 Setup
MultiControl AI and BI
1 Magnetic sensor 9 Motor RD 4 connection
2 LED for connections on the left 10 Sensor 4 / I/O 4 connection
3 Control status LED 11 Fastening screw
4 LED for connections on the right 12 Rating plate
5 Identication plate 13 Sensor 2 / I/O 2 connection
6 Sensor 3 / I/O 3 connection 14 Motor RD 2 connection
7 Motor RD 3 connection 15 Motor RD 1 connection
8 Bus connection 16 Sensor 1 / I/O 1 connection
17 Functional earth connection
