48 of 140
Version 2.5 (11/2020) UL
Translation of the original operating manual
Start-up and operation
Teach-in
WARNING
Risk of crushing due to unintentional start-up of the RollerDrive!
¾ Changes in this menu have direct inuence on the connected RollerDrive!
¾ Before starting motors make sure, ensure that no persons are present in the hazardous areas surrounding
the conveyor system!
Teach-in
Submit
Init
Start
Finish
Abort
Reset
Teach-in Feature
Please read the manual before trigger any of the options below!
Plug&Play
Plug&Play
Submit
Enabled
Plug and Play Feature
The "Teach-in" and "Plug&Play" functions are described in the "MultiControl / RollerDrive - Start-up and
Programming" supplement.
CAN Gateway
CAN Gateway
Send
Mode
CAN Bus Terminal
Node ID Sub IdxSDO Idx Length Data
Read
Write
dec num hex num hex num dec num hexabytes, e.g. 0FF640
Node 0>> Response: Unknown, Error: 0
Only used for service purposes.
