Interroll MultiControl AI User Manual

44 of 140
Version 2.5 (11/2020) UL
Translation of the original operating manual
Start-up and operation
Control Program Settings
Control Program Settings
Submit Reset
Control Program Settings
Program ID :
Version : 2017-12-12-11
Control Timer
Timer 1 [ms] :
Timer 2 [ms] :
Timer 3 [ms] :
Timer 4 [ms] :
I/O Device

0
0
0
0
Selection of control programs
ZPA single release program
ID
ZPA train release program
ID
ZPA module program
ID
No ZPA program ID
Single release 1 zone Train release 1 zone ZPA transfer in I/O device
Single release 2 zone Train release 2 zone ZPA transfer out
Single release 3 zone Train release 3 zone ZPA merge
Single release 4 zone Train release 4 zone ZPA HPD
HPD semiautomatic
Transfer semiautomatic
Control Timer
Timer 1: Single release: Transfer communication time
Train release: Time-delayed start of the RollerDrive
Timer 2: Internal monitoring of the material to be conveyed
Timer 3: RollerDrive overrun
Timer 4: Error reset
The functions and default settings for the timers vary depending on the selected control program (see
the description of control programs in the "MultiControl / RollerDrive - Start-up and Programming"
supplement).
Press the "Submit" button to transfer the modied parameters to the MultiControl.
