Start-up and operation
Motor Monitor – MultiControl BI only
Motor Monitor
Motor 3 Motor 4Motor 2Motor 1
Start/Stops
Run Time (hh:mm:ss)
Up Time (hh:mm:ss)
Temp. Max (°)
Temp. Min (°)
Current Temp. (°)
Num. Quick Stops
Actual Torque (mNm)
Power/Time (Wh)
Num. Rotations
Lifetime
Temperature
Power
Error
31536065
3140:26:15
8984:58:28
99
16
20
0
0
0
172911880
177
0:19:42
288:45:16
46
16
21
0
0
0
2174
---
---
---
----
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
Visual displays
Service life indicator lights
Health indicator lights for:
• Temperature
• Power
• Frequency of errors
Monitoring data
Start/stops – Number of start/stops per minute
Run time (s)
Up time (s)
Temp. max (°C) – Maximum temperature of the motor electronics
Temp. min (°C) – Minimum temperature of the motor electronics
Current temp. (°C) – Actual temperature of the motor electronics
Num. quick stops – Number of quick stops
Actual Torque (mNm) - Actual Torque
Power/time (Wh) – Average mechanical power output
Num. rotations – Number of motor revolutions
