40 of 140
Version 2.5 (11/2020) UL
Translation of the original operating manual
Start-up and operation
Motor Test for EC5000
WARNING
Risk of crushing due to unintentional start-up of the RollerDrive!
¾ Changes in this menu have direct inuence on the connected RollerDrive!
¾ Before starting motors make sure, ensure that no persons are present in the hazardous areas surrounding
the conveyor system!
Motor Test for EC5000
Motor CommandsSelect effected MotorsSimple Test
Start all Motor 1
Motor 2
Motor 3
Motor 4
Velocity Mode:
stopCCW CW
Stop all
Start all motors in positive direction
¾ Select the desired motor
¾ Select the test:
• Simple test – Starts all connected motors in a positive rotational direction
• Velocity mode – Start and stop selected motors clockwise or anti-clockwise
