Version 2.5 (11/2020) UL
Translation of the original operating manual 43 of 140
Start-up and operation
Function Description
Control output 3 Zone 3 occupied
Control output 4 Zone 4 occupied
Control output 5–8 No function
Handshake in up Handshake signals to neighbouring ZPA modules
Handshake in down
Handshake in left
Handshake in right
Handshake out up
Handshake out down
Handshake out left
Handshake out right
VDC motor #1 error in VDC motor error input
VDC motor #2 error in
VDC motor #1 direction out VDC motor directional rotation
VDC motor #2 direction out
VDC motor #1 step pulse out VDC motor pulse output
VDC motor #2 step pulse out
The functions have no inuence on the “I/O device” control program.
Shutdown Aux Output
Not activated The aux outputs are reset when the RollerDrive voltage is switched o and cannot be
controlled.
Activated The Aux outputs keep their current status when the RollerDrive voltage is switched o and can
still be controlled.
The functions vary depending on the selected control program (see the description of control programs in
the "MultiControl / RollerDrive - Start-up and Programming" supplement).
Press the "Submit" button to transfer the modied parameters to the MultiControl.
