Interroll MultiControl
Initial startup and operation
26 Version 2.3 (01/2017) en-US
Translation of original instruction manual
No. LED Function
1 Sensor 1 Cancel
2 I/O 1 Set sensors
3 RD 1 Set bus type
4 RD 2 Teach-In procedure
5 Sensor 2 Switch LED indicators on or off
6 I/O 2 Reset MultiControl to factory settings
4 To select a function, remove the magnet if the respective LED is lit.
2 seconds after removing the magnet, the selection of the function is accepted. During this
time, the LEDs "Ready" and "Com" as well as the LED that belongs to the selection are
flashing. If a second selection belongs to this function, the LED of the previous selection is
flashing for approx. 7 seconds (see table below).
4 To change this second selection, hold the magnet against the magnetic sensor again after
2 seconds.
Running lights are lighting up on the LED bar on the right side of MultiControl, which can be
used to perform additional settings in the same way. The selection is accepted 5 seconds
after removing the magnet.
Function Selection Selection No. LED
2: Set sensors PNP Normally Closed 1 Sensor 3
NPN Normally Closed 2 I/O 3
PNP Normally Open 3 RD 3
NPN Normally Open 4 RD 4
3: Set bus type EtherCAT 1 Sensor 3
PROFINET 2 I/O 3
EtherNet/IP 3 RD 3
4: Teach-In procedure Read in motors 1 I/O 3
Start Teach-In 2 RD 4
Cancel Teach-In 3 Sensor 3
6: Reset MultiControl to factory
settings
Confirmation I/O 4
