Initial startup and operation
Version 2.3 (01/2017) en-US
Translation of original instruction manual
27
LED indicators when using the magnetic sensor
When the magnetic sensor recognizes the magnet, the "Fault" LED is permanently lit. If the
setting via the magnetic sensor is activated, the LEDs "Ready" and "Com" are also flashing at
1Hz.
LED State Meaning
Sensor 1 On Function 1: Cancel
I/O 1 On Function 2: Set sensors
RD 1 On Function 3: Set bus type
RD 1 +
Sensor 3
On Selection 1 for function 3: EtherCAT
RD 1 +
I/O 3
On Selection 2 for function 3: PROFINET
RD 1 +
RD 3
On Selection 3 for function 3: EtherNet/IP
RD 2 On Function 4: Teach-In procedure
Sensor 2 On Function 5: Switch LED indicators on or off
I/O 2 On Function 6: Reset MultiControl to factory settings
I/O 2 +
I/O 4
On Confirmation for function 6: Reset MultiControl to factory settings
Sensor 3 Flashes 1 Hz Loading EtherCAT stack
I/O 3 Flashes 1 Hz Loading PROFINET stack
RD 3 Flashes 1 Hz Loading EtherNet/IP stack
Together with the following displays, the LEDs "Ready" and "Com" are flashing at 2Hz, the
"Fault" LED is off.
LED State Meaning
RD 1
Sensor 3
On
Flashes 2 Hz
"EtherCAT" selection active, magnetic sensor not (any longer)
actuated
RD 1
I/O 3
On
Flashes 2 Hz
"PROFINET" selection active, magnetic sensor not (any longer)
actuated
RD 1
RD 3
On
Flashes 2 Hz
"EtherNet/IP" selection active, magnetic sensor not (any longer)
actuated
I/O 2
I/O 4
On
Flashes 2 Hz
Confirmation for function 6: Reset selected, magnetic sensor not
(any longer) actuated

Interroll MultiControl Specifications

General

Power Supply	24 VDC
Rated Voltage	24 VDC
Storage Temperature	-20 °C to +70 °C
Communication Protocols	Ethernet/IP, PROFINET, EtherCAT, CANOpen
Number of Channels	4
Weight	0.5 kg
