Chapter 1 Overview of NVR
1.1 Front Panel
NVR Front Panel, as shown in figure 1-1-1
Figure 1-1-1 Front panel of M1 case
No.
Function Description
1
Network status light
2
Hard disk status light
3
Power status light
4
USB interface
Table 1-1-1 Description of front panel
● All above drawings are for reference only
