Goodrive350 IP55 High-ingress Protection Series VFD Basic Operation Instructions
-51-
Function
code
Name
Description
Default
value
3: AI3
4: Pulse frequency HDIA
5: Multi-step
6: Modbus/Modbus TCP communication
7: PROFIBUS/CANopen/DeviceNet
communication
8: Ethernet communication
9: Pulse frequency HDIB
10: EtherCAT/PROFITNET/Ethernet IP
communication
11: PLC
12: Reserved
Note: For these settings, 100% corresponds
to the max. frequency.
P03.15
Source of upper limit
frequency setup of reverse
rotation in torque control
0: Keypad (P03.17)
1–11: the same as P03.14
0
P03.16
Keypad limit value of upper
limit frequency of forward
rotation in torque control
Value range: 0.00 Hz–P00.03 (max. output
frequency)
50.00Hz
P03.17
Keypad limit value of upper
limit frequency of reverse
rotation in torque control
50.00Hz
P03.18
Source of upper limit setup
of the torque when
motoring
0: Keypad (P03.20)
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDIA
5: Modbus/Modbus TCP communication
6: PROFIBUS/CANopen/DeviceNet
communication
7: Ethernet communication
8: Pulse frequency HDIB
9: EtherCAT/PROFITNET/Ethernet IP
communication
10: PLC
11: Reserved
Note: For these settings, 100% corresponds
to the motor rated current.
0
P03.19
Source of upper limit setup
of brake torque
0: Keypad (P03.21)
1–10: the same as P03.18
0
