6700SR Refrigerated Sampler
117
Figure 33 Extended Programming: Equipment Setup
NUMBER OF BOTTLES:
1 2 4 8 12 24
BOTTLE VOLUME IS
_____ ml (300-30000)
SUCTION LINE LENGTH
IS __ ft
(3-99)
AUTO SUCTION HEAD
ENTER HEAD
_ RINSE CYCLES
(0-3)
RETRY UP TO _ TIMES
WHEN SAMPLING
(0-3)
ONE-PART PROGRAM
TWO-PART PROGRAM
__ BOTTLES AVAILABLE
ASSIGN BOTTLES
1 THRU __ TO
PART 'A' (1-max)
SUCTION HEAD OF
__ ft
(min-max)
Continued from
Figure 32
, Extended
Programming: Programming Screens
, on
page 116.
See
Figure 34
, Extended Programming: Pacing
and Distribution , on page 118.
