6700SR Refrigerated Sampler
118
Figure 34 Extended Programming: Pacing and Distribution
See Note A.
A. Event-paced programs always
use sequential distribution
.
Notes
UNIFORM TIME PACED
FLOW PACED
EVENT PACED
NONUNIFORM TIME
NONUNIFORM TIME:
CLOCK TIMES
INTERVALS IN MINUTES
RANDOM INTERVALS
FLOW BETWEEN
SAMPLE EVENTS:
____ PULSES (1-9999)
PACED BY:
FLOW PULSES
FLOW MODULE VOLUME
QUANTITY AT INTERVAL
1. __ AT ___ MIN
2. __ AT ___ MIN
3. __ AT ___ MIN
FIRST SAMPLE AT
START TIME,
THEN ...
SAMPLE AT START?
YES NO
PROGRAM RUN TIME:
__ HOURS, __ MINUTES
TIME BETWEEN
SAMPLE EVENTS:
__ HOURS, __ MINUTES
TAKE SAMPLES AT:
1. START TIME
2. HH:MM
3. HH:MM
TAKE ___ SAMPLES
(1-999)
RUN CONTINUOUSLY?
YES NO
RUN CONTINUOUSLY?
YES NO
DO YOU WANT TO
RUN CONTINUOUSLY?
YES NO
__ BOTTLES PER
SAMPLE EVENT (1-max)
SWITCH BOTTLES EVERY
___ SAMPLES (1-max)
SWITCH BOTTLES ON:
NUMBER OF SAMPLES
TIME
SWITCH BOTTLES EVERY
__ HOURS, __ MINUTES
FIRST SWITCH TIME
AT __:__
1 bottle
No
Multi-bottle
DO YOU WANT
SAMPLE VOLUMES
DEPENDENT ON FLOW?
YES NO
FLOW PULSES
FLOW MODULE VOLUME
SAMPLE VOLUME:
___ ml (10-max)
SAMPLE VOLUME:
10 ML FOR EVERY
___ PULSES
Ye s
Ye s
Uniform Time Paced Only
All other pacing
No
Continued from
Figure 33
,
Extended
Programming: Equipment Setup
, on page 117.
See
Figure 35
,
Extended Programming:
Programmed Sampler Enable
, on page 119.
To Next Page
