6700SR Refrigerated Sampler
34
Example 6 Storm Water Runoff Sampling (continued)
54
SWITCH BOTTLES EVERY
1
SAMPLES (1- 50)
Enter 1.
55
RUN CONTINUOUSLY?
YES
NO
Select NO.
56
SAMPLE VOLUME:
500
ml (10-1000)
Enter 500.
57
ENABLE:
I/O
RAIN
LEVEL
FLOW Y-pH Y-TEMP
Y-COND Y-D.O. NONE
Select RAIN.
58
ENABLE: RAIN
AND
OR DONE
Select AND.
59
ENABLE: RAIN AND
I/O RAIN
LEVEL
FLOW Y-pH Y-TEMP
Y-COND Y-D.O. NONE
Select LEVEL.
60
“RAIN” SET POINT:
0
.
15
INCHES PER
15 MIN
30 MIN
1 HOUR 2 HOURS
Enter 0.15 for inches, then select 30 minutes.
61
ENABLED WHEN:
ABOVE SET POINT
BELOW SET POINT
Select ABOVE SET POINT.
62
RESET RAIN HISTORY?
YES
NO
Select YES.
63
“LEVEL” CONDITION:
SET POINT
RANGE
Select SET POINT.
64
“LEVEL” SET POINT
0
.
25
ft
(0.100-30.000)
Enter 0.25.
65
ENABLED WHEN:
ABOVE SET POINT
BELOW SET POINT
Select ABOVE SET POINT.
66
ONCE ENABLED,
STAY ENABLED?
YES
NO
Select YES.
