PAMSPAN501x G.SHDSL.bis EFM Gateway
-89
2. User Priority to Regenerated Priority Map, as shown is the following figure,
specifies the mapping of user priority in the incoming frames to the regenerated
user priority that will be used for Traffic Class mapping, as well as being set in the
VLAN tag of the outgoing frame.
The following table gives the range of values for each option that can be specified
using this command, and a default value.
Option Description Default value
Priority 0 The Regenerated User Priority to which the user priority with
a value of 0 in the incoming frame should be mapped.
0
Priority 1 The Regenerated User Priority to which the user priority with
a value of 1 in the incoming frame should be mapped.
1
Priority 2 The Regenerated User Priority to which the user priority with
a value of 2 in the incoming frame should be mapped.
2
Priority 3 The Regenerated User Priority to which the user priority with
a value of 3 in the incoming frame should be mapped.
3
Priority 4 The Regenerated User Priority to which the user priority with
a value of 4 in the incoming frame should be mapped.
4
Priority 5 The Regenerated User Priority to which the user priority with
a value of 5 in the incoming frame should be mapped.
5
Priority 6 The Regenerated User Priority to which the user priority with
a value of 6 in the incoming frame should be mapped.
6
Priority 7 The Regenerated User Priority to which the user priority with
a value of 7 in the incoming frame should be mapped.
7
