iteco IT 10122 - Description

OPERATING AND MAINTENANCE HANDBOOK
Description
The here described platform is a machine able to travel, steer, li and
lower the platform.
The truck is outt of two front steerable drive wheels to travel and
steer; the two back wheels are idler.
Traction and liing operations are controlled by proportional control
device respectively operated by two electric motors ed on front
wheels and by an electrical pump.
The control and power instruments are installed in the three boxes
and in the middle of the truck:
Right box
IT10122 - IT12122
To li and lower the platform two cylinders work on the scissors
supporting the platform surrounded by overturning railings and
protections.
The traction movement is electrically-operated; the liing lowering
and steering movements are hydraulically-operated.
1 Fuses
2 Liing electric pump
3 Steering electric pump
1
2
3
Steering is operated by an electric pump that supplies a hydraulic
cylinder with energy.
The energy of each machine is supplied by electric baeries that feed
the electric motors and the electric pumps.
