Maintenance devices
Safety rest
If the platform is subjected to maintenance while lied, lock the liing
system on both sides by means of the suitable rests supplied with the
machine (pos.1).
Use the safety supports only when platform is unloaded
Lock the liing system as described hereaer:
• Li the platform so as the distance between scissors is 50 cm. ap-
prox.
•Unscrew the knobs which block each rest (right and le) to the rel-
evant arm, leaving them hang downwards.
•Lower the platform making sure that the lower fork of each rest (right
and le) t in the housing obtained in the central pivot extremity of
the lower scissors.
•Before starting the maintenance works, make sure that both rests are
rmly rested on the side slots obtained on the pivot.
•Once works have been nished, li a lile the platform to release the
rests, and x them again to the arm by means of locking screws.
