OPERATING AND MAINTENANCE HANDBOOK
Steering
• During traction press switches 9 of joystick 8 to the right or le in
order to steer in the desired direction.
In order to turn the wheels when the machine is stationary, bring
joystick 8 into the central position and use switches 9 as described
before.
The “man present” push buon 10 should be always pressed.
Before moving the machine, make sure that the way is free from
obstacles, holes, bumps, unevenness, obstructions or debris and that
no coverings are there, which can hide holes or other dangers.
Always check the state of pilot lights ; in case they go on, please,
read section “Emergencies”
8
9
9
8
10
IT10122 - IT12122
