OPERATING AND MAINTENANCE HANDBOOK
Inclination
Carry out this test with the machine perfectly levelled, for avoiding
altered values.
Carry out this test by using platform control panel.
Do not stop on the platform.
Make sure that there are no obstacles above or under the platform
before carrying out this test.
•Lower platform completely.
- under each wheel of front axle for rear longitudinal inclination;
drive the machine on it; li platform and carry out tests reported
on the following page;
- repeat the above mentioned test positioning the wedges under each
wheel of rear axle.
During the second test, the machine must be put in the same position
with respect to the ground, while altering the wedge position (See
drawing on the side).
SQ1 Microswitch
Safety speed
Make sure that there are no obstacles above or under platform before
carrying out this test.
•Li platform above microswitch SQ1 operating height from platform
control panel.
•Check that drive is possible at safety speed only.
IT10122 - IT12122
•Position a wedge A measuring about 97 mm:
To Next Page
