OPERATING AND MAINTENANCE HANDBOOK
Overall dimensions
IT10122 - IT12122
A B
C (Pot-hole up
/ down)
D E F
IT 10122 10020 12020
120/24
2410 1280 1980
IT 12122 11900 13900 2540 1410 2110
