OPERATING AND MAINTENANCE HANDBOOK
Emergencies
Pilot light 7 in the ground control panel and pilot lights 15-16-17-18 of
platform control panel signal, if ON, emergency situations, with the
following partial or total stopping of the machine movements.
Overload
PILOT LIGHT 7 and 17 A charge limiting device comes into operation in case of overload on
the platform: all the movements are stopped.
• The total block of all the movements is signalled by:
- pilot light 7 on ground control panel going on.
- pilot light 17 on platform control panel going on.
- an audible alarm.
• In order to restore movements it is necessary:
- to remove the excessive load
7
15
16
18
17
IT10122 - IT12122
