iteco IT 10122 - Platform Control Panel

OPERATING AND MAINTENANCE HANDBOOK
Platform control panel
8 Traction and liing control joystick
9 Steering control switches
10 Push buon man-present
11 Red emergency stop push buon
12 Horn buon
13 Drive speed selector
14 Traction or liing function selector
15 General diagnostic pilot light
16 Pilot light unstable machine
17 Overload pilot light
18 Protections against overturning pilot light
11
15
18 17
16
14
8
9
12
13
9
8
10
IT10122 - IT12122
