OPERATING AND MAINTENANCE HANDBOOK
Safety systems
Microswitches
Some microswitches are positioned on the machine with safety fun-
ctions.
SQ1 Microswitch
•Enables the atness indicator which locks the machine movements
if this last exceeds the maximum slope, except for the lowering op-
eration.
•Inserts the drive reduced speed.
• Prevents traction and steering movements in case the protections
against overturning are not lowered (combined with SQ6A-SQ6B
microswitches).
IT10122 - IT12122
The SQ1 microswitch has enabled through the platform liing move-
ment
SQ5 Microswitch
The SQ5 microswitch, placed on the le back part of the base truck
has enabled through the platform liing movement to a height of 2.25
m (IT10122) - 2.45 m (IT12122) from the oor surface.
• Prevent traction and steering movements in case the protections
against overturning are not lowered (combined with SQ6A-SQ6B
microswitches).
SQ1 is formed by a proximity sensor system and it is composed of:
- A rectangular-shaped magnetic unit
- A rectangular-shaped sensor with contacts.
SQ1 condition not activated
With the platform rest the sensor and the magnetic unit are near.
SQ1 condition activated
With platform lied when the sensor and the magnetic unit are sepa-
rated for more than 3 cm.
