OPERATING AND MAINTENANCE HANDBOOK
3
4
2
1
Traction controlled from ground
To pass through openings having limited height, it is possible to drive
the machine from ground using the platform control panel (push but-
ton panel on board), making sure that:
• the railings are overturned (1);
• the operator remains at a minimum distance of 1 m from the ma-
chine;
• the selected speed is the slower one;
• the machine is entirely lowered (closed) (2);
• make use of the direction arrows being on the control box support
(3) and on the upper side frames (4), in order to locate in one way
the direction of steering and drive.
IT10122 - IT12122
