OPERATING AND MAINTENANCE HANDBOOK
•Retract the platform.
•Bend the platform access protection bar as shown in the above gure
and extract the spring plungers.
•Take the spring plungers away from hinged points and overturn the
side protections.
Do not use the machine with overturned railings remaining on board
of the machine.
IT10122 - IT12122
