DAILY 4x4 ‒ GUIDELINES FOR BODYBUILDERS
POWER TAKE-OFFS
4.6 PTO MANAGEMENT
9
– Printed 692.68.999 – 3 Ed. - Base 08-2020
208927
Figure 4
The control unit is also able to perform the control of the set revolutions and maintain or restore balance depending on the ap-
plied load.
Note
The adjustment of engine speed through Cruise Control (Working Engine Speed Demand) may only be performed with the vehicle
stationary or when the vehicle speed is less than between 10 and 20 km/h, depending on the vehicle version.
After turning the selector of Figure 4 in the ON position, actuating in the direction + or - makes it possible to increase or decrease
the number of revolutions in two ways:
a) with steps of 50 rpm if the lever is operated for between 0.5 and 2 seconds;
b)with a ramp of 400 rpm for each second of continuous activation of the lever, beyond 2 seconds.
It is possible to store a new speed (with PTO on) by pressing and holding the RESUME button for at least 5 seconds.
With Cruise Control activated, it is possible to return to the minimum engine speed condition (setting cancelled) by placing the
selector shown in Figure 4 on OFF, or by pressing the brake pedal or clutch pedal.
4.6.2 After-sales installation of PTO
If PTO is to be installed in after-sales, then it is necessary to check the following:
● that the vehicle is equipped with the Cruise Control opt.;
● obtain approval for the intervention from IVECO and any specific instructions that may be required.
Note
The after-sales installation of a PTO means that once installation is complete, IVECO Assistance Service must be contacted in order
for the software of the engine control unit, the BDV control unit and, if present, the automatic transmission control unit to be up-
dated via teleservices.
