DAILY 4x4 ‒ GUIDELINES FOR BODYBUILDERS
CHASSIS INTERVENTIONS
2.3 RUST AND PAINT PROTECTION
– Printed 692.68.999 – 3 Ed. - Base 08-2020
Reinforcement anchorage must regard only the vertical rib of the side member and can be realised with a weld bead, staples,
bolts or nails (even Huck nails).
Area and length of the weld bead, number and distribution of staples, number of nails of bolts must be adequate to transmit
the bending and shearing moments.
● Once work is complete, use anti-rust protection (see Paragraph "Added or Modified Parts" ( ➠ Page 12)).
2.2.4 Closing holes by welding
If new holes are located near old holes, (see Figure 2), these last can be welded shut.
Good results are obtained by:
● chamfering the outer edge of the hole;
● applying a copper plate on the inner edge of the side member to hold the welding material;
● welding the side member on both sides with elimination of all residual material.
Holes of 20 mm diameter can be sealed off by using chamfered washers welded on both sides.
2.3 RUST AND PAINT PROTECTION
Note
All components mounted on the chassis must be painted in compliance with IVECO Standard 18-1600 Colour IC444 RAL 7021 -
70/80 gloss.
2.3.1 Original vehicle components
The following tables show, respectively, the classes of coating and protection required for the original vehicle components, the
protections required for the parts not painted or in aluminium and treatments required for the painted parts.
Table 2.4 - Class of protection - IVECO Standard 18 - 1600 (Prospectus I)
Class Part requirements Examples of parts involved
A Parts in direct contact with atmospheric agents
Bodywork - Rear-view mirrors - Windscreen wipers -
Metallic structured sun visors - Metallic bumpers -
Cab hook lock - Door stop device -
Bodywork fastening elements (screws, bolts, nuts, washers), etc.
B
B2
Parts in direct contact with atmospheric agents that mainly have
structural characteristics, in clear sight
Chassis and relative parts, including its fasteners
Parts below the front grille (class B)
External cab footboards
B1 Only for rear axles and front axles
C Parts in direct contact with atmospheric agents, not in clear view Engine and relative parts
D Parts not in direct contact with atmospheric agents
Pedals - Seat coverings - Fastening elements - etc.,
mounted inside the cab
Table 2.5 - Unpainted aluminium parts - IVECO Standard 18 - 1600 (Table IV)
Type of protection
IVECO
standard
Classes
A B - B1 - B2 C D
Stainless steel
(1)
18-0506 – – – –
Geomet
(2)
GEO 321-8
18-1101 yes – – –GEO 500-8
GEO 321-8 PM
