42
DAILY 4x4 ‒ GUIDELINES FOR BODYBUILDERS
ELECTRONIC SUB-SYSTEMS
5.8 MISCELLANEOUS
– Printed 692.68.999 – 3 Ed. - Base 08-2020
Table 5.13 - 13-pole trailer socket
Pin Description Cable code Remarks
1 Rear left turn indicator 1120 1 21 W - 12 V lamp
2 Rear fog lamp power supply 2283 2 21W - 12V lamps
3 Ground 0000 –
4 Rear right turn indicator 1125 1 21 W - 12 V lamp
5
Front left and rear right parking light
Left license plate light and left side marker light
3335 3 5 W - 12V lamps
6 Stop signal lights power supply 1175 2 21W - 12V lamps
7
Front right and rear left parking light.
Right license plate light and right side marker light
3334 3 5 W - 12V lamps
8 Power supply for reverse light 2268 2 21W - 12V lamps
9 After fuse F67 present on SCM1/B 7777 Battery positive
10 After fuse F49 present on Body Computer 8879 Positive with key
11 Ground 0000 –
12 Trailer connection signal (Ground) 6676
1. Signal to be supplied through connection on the trailer,
to permit trailer lights and parking sensor diagnostics (if
present)
2. Pin 12 could be absent as it may have been replaced
by a switch integrated in the socket; in this case it is not
necessary to perform any connection on the trailer
13 Ground 0000 –
▶ The electrical connection of a trailer entails a considerable increase in the length of the cables
and results in a larger voltage drop on the line. Therefore the use of cables with the biggest pos-
sible cross-section is recommended, which are compatible with the system layout and with the
13-pin socket; on this it is then necessary to the split the ground return using pins 3, 11 and 13.
5.8.4 Installation of lateral side lights (Side Marker Lamps)
EC regulations require that vehicles are provided with side and clearance lights when the total length exceeds 6 m.
The installation of the lateral lights must be performed on the additional structures (containers, vans, etc.), when not required by
regulations, while the electric power supply must be obtained by the specific ST38 connector on the chassis (see Figure 44).
In order to keep the electrical characteristics of the contacts of the female socket unchanged, the hood supplied by IVECO must be
left attached.
▶ It is not possible to draw current from side marker lights.
