DAILY 4x4 ‒ GUIDELINES FOR BODYBUILDERS
Hi-MATIC AUTOMATIC GEARBOX
C.3 REQUIREMENTS
7
– Printed 692.68.999 – 3 Ed. - Base 08-2020
C.3.3 Propeller shaft
261978
Figure 4
The automatic gearbox requires a specific propeller shaft for length and for the coupling joint (1).
Any modifications which involve changes in one or more of these characteristics (e.g. wheelbase modification), are the full respons-
ibility of the person who makes these modifications.
C.3.4 Rear cross member
A specific crossbar is mounted to support the transmission from the rear (following Figure); despite this fact, in comparison to
manual transmission vehicles, the comparability with structures installed behind the cab (e.g. crane) remains the same.
Careful verification is advised before proceeding.
261979
Figure 5
