DAILY 4x4 ‒ GUIDELINES FOR BODYBUILDERS
ELECTRONIC SUB-SYSTEMS
5.6 ADDITIONAL EQUIPMENT
33
– Printed 692.68.999 – 3 Ed. - Base 08-2020
This device consists of an aerial fitted onto the roof.
To install, carry out the following operations:
● drill a 20 mm hole on the roof in the position indicated in the figure;
● protect the hole with an anti-corrosion treatment;
● position the aerial (1) on the roof and secure it using the nut (2) supplied;
● tighten to a torque of 7 Nm;
● connect the two connectors (3) of the aerial with the connectors on the vehicle.
▶ If devices are fitted which could interact with the electronic systems already present (retarders,
additional heaters, power take-offs, air conditioners, automatic gearboxes, telematics and speed
limiters) please contact IVECO in order to establish the compatibility checks.
▶ Any damage caused by the use of non-certified transceivers or by the application of additional
amplifiers is not covered by the warranty.
5.6 ADDITIONAL EQUIPMENT
Power for the equipment, when the voltage required is different to that for the system, must be obtained using a suitable DC/DC
12-24V converter if not already provided. The power cables must be as short as possible, avoiding any twists (coils) and maintaining
the minimum distance from the reference plane.
Note
If devices are fitted which could interact with the electronic systems already present (retarders, additional heaters, power take-offs,
air conditioners, automatic gearboxes, telematics and speed limiters) please contact IVECO in order to establish the compatibility
checks.
▶ The use of non approved transmitters or supplementary amplifiers could seriously impede the
correct functioning of the electrical/electronic devices normally supplied, with negative effects
for the safety of the vehicle and/or the driver.
▶ Any damage caused by the use of non-certified transceivers or by the application of additional
amplifiers is not covered by the warranty.
The vehicle system is set up to supply the necessary power to the equipment provided, for each of which, as part of their function,
the specific protection is assured as well as the correct sizing of cables.
The installation of additional equipment must include suitable protections and should not overload the vehicle system.
The connection of the added users to ground must be made with an adequately sectioned cable, as short as possible and made to
allow for any movements of the added equipment with respect to the chassis of the vehicle.
Having the need for higher capacity batteries, due to added loads, it is appropriate to request the optional with increased batteries
and alternators.
In any case, when increasing battery capacity, it is advisable not to exceed 20-30% of the maximum values provided as optional by
IVECO, so as not to damage some of the components (e.g. starter motor). When higher capacities are necessary, use additional
batteries, making the necessary provisions for recharging as indicated below.
