44
DAILY 4x4 ‒ GUIDELINES FOR BODYBUILDERS
ELECTRONIC SUB-SYSTEMS
5.8 MISCELLANEOUS
– Printed 692.68.999 – 3 Ed. - Base 08-2020
5.8.5 Reverse gear signal
For safety reasons, certain vehicle versions must emit an external reversing warning sound which is activated when the vehicle is
reversing.
This safety device may be originally requested as opt. 7638, regardless of the type of gearbox used.
Application is recommended inside the rear cross member of the licence plate holder, as in Figure 45.
262156
Figure 45
1. Reverse buzzer 2. Reverse gear signal cable
This device is operated by a connector ST79 with three terminals with safety cap.
