24
DAILY 4x4 GUIDELINES FOR BODYBUILDERS
CHASSIS INTERVENTIONS
2.6INSTALLING THE TOW HOOK
Printed 692.68.999 3 Ed. - Base 08-2020
The following chart contains the data of tow hook versions which are available in production.
  Table 2.12 - Type-approved hooks
EC certified Type Class D [kN] Dc [kN] S [kN] V [kN]
E2 55R-01 12209 CR32C S 31 31 340
E1 55R-01 2262 2020 S 30 30 350 18
E3 55R-01 3020 HRC10 K3 30 24.5 400 16
E3 55R-01 3040 BC40 A50-X 23.41 250
If it is not directly supplied by IVECO, then the tow hook must in any case:
have characteristics that are wholly equivalent to those shown in Table 2.12;
be approved in observance of the current national and international legislation (e.g. EU Directives);
be fitted in accordance with the manufacturer's instructions.
Note
Any other solutions must be explicitly authorised by IVECO.
2.6.4Observations on payload
The static load on the tow hook must not exceed the load allowed on the rear axle of the vehicle. Furthermore, the minimum
weight on the front axle must be respected as indicated in Chapter 1.15 .
2.6.5Increase of towable weight
As regards tow vehicles, IVECO may evaluate - in certain cases and for particular applications - the possibility to authorise greater
tow weights than those normally allowed.
These authorisations include the towing conditions and, when necessary, provide the instructions relevant to any vehicle modifica-
tions or work required: standard crossbar reinforcements, or installation of a reinforced crossbar when available, or adjustments to
the braking system.
The tow hook must be suited for the new use, and its connection flange must coincide with that of the crossbar.
Fix the crossbar to the chassis by using flanged head screws and nuts or hex head screws of 8.8 min. class.
Use anti-unscrewing systems.
2.6.6Nameplates
Some countries require a plate to be applied on the towing device, which must list maximum tow load and maximum vertical load
allowed.
If not already mounted, the Bodybuilder shall see to its manufacture and installation.
