30
DAILY 4x4 ‒ GUIDELINES FOR BODYBUILDERS
ELECTRONIC SUB-SYSTEMS
5.5 RECEIVER-TRANSMISSION SYSTEMS
– Printed 692.68.999 – 3 Ed. - Base 08-2020
5.5.2 Bluetooth pre-installation
The Bluetooth setup consists of:
● specific control unit, positioned above the radio and hidden by a plastic cover;
● buttons on the steering wheel;
● ceiling fixture with microphone;
● USB socket;
● wiring.
208938
Figure 30
1. Buttons on the steering wheel 2. USB port
For cowl version vehicles the ceiling fixture with microphone is provided in the box of accompanying material.
If required by installation in the cab, the microphone can be removed and recovered (see Figure 31); its position, however, must be
at a point as far away as possible from sources of noise and according to the reception area described in the (see Figure 32).
