DAILY 4x4 ‒ GUIDELINES FOR BODYBUILDERS
ELECTRONIC SUB-SYSTEMS
5.5 RECEIVER-TRANSMISSION SYSTEMS
31
– Printed 692.68.999 – 3 Ed. - Base 08-2020
208947
Figure 31
1. Bluetooth microphone
208949
Figure 32
1. Driver's side 2. Passenger side
Table 5.9
Pin Description Cable
1 Ground White
2 Signal + Vcc Shielded
The connector of the microphone connection, on the cab wiring side, is located in correspondence with the ceiling connectors.
