DAILY 4x4 ‒ GUIDELINES FOR BODYBUILDERS
EXPANSION MODULE
7.2 WIRING DIAGRAM
7
– Printed 692.68.999 – 3 Ed. - Base 08-2020
Pin Description
Cable
code
Signal
Connected
to
Remarks
12 Scene light switch 0992
Input
5 mA
EM X3/18
(1) (5)
+12 V = scene lights activation
0 V = no action
13 Additional light switch 1 0993
Input
5 mA
EM X3/19
(1) (5)
+12 V = additional lights 1 activation
0 V = no action
14 Additional light switch 2 0994
Input
5 mA
EM X3/20
(1) (5)
+12 V = additional lights 2 activation
0 V = no action
15
EMCY bodybuilders
(For future applications)
0995
Input
5 mA
EM X3/21
Input to activate the Vehicle Stopped Status, only if the Body-
builder enable input is also activated (61071B / Pin 18)
Ground = activate low side switch
Open wire = no action
16 PTO 2 switch 0391
Input
5 mA
EM X3/11
PTO 2 mode
(5)
Open circuit = not activated
Ground = activated
Without physical PTO, ISC Mode 2 activated
17 PTO 3 switch 0123
Input
5 mA
EM X3/7
PTO mode 3 (only for ISC)
(5)
Open circuit = not activated
Ground = activated
18 Bodybuilder Enable 0991
Input
5 mA
EM X3/17
To be activated by Bodybuilder with Bodybuilder mission active
Ground = activate low side switch
Open wire = no action
19 Spare 5983 EM X4/29
20 Run-Lock relay 6987
Output
1 A
EM X4/1
Possible reconfiguration via Customer Service (CS)
+12 V = RunLock activated
No signal = RunLock not activated
(1)
Activation requires programming by Customer Service. Please contact IVECO After-Sales Service.
Output supported only during K15 ON. With K15 Off, the outputs are disabled.
(2)
With the Additional Lights function enabled, the PTO functions are no longer available (see Chapter 7.3 (
➠
Page 10)).
This also applies for activation of the PTO / ISC saved speeds for PTO Mode 1, 2, 3; these functions are also no longer available.
(3)
If Additional Light 1 or Blue Light 1 are activated by Customer Service, then full vehicle CAN operation 72075B / 12 is no longer available
(see Chapter 7.3 (
➠
Page 10)).
In order to avoid any problems IVECO requests that the relay is disassembled for full vehicle CAN operation.
(4)
The RunLock function is used for missions where the operator is not inside the cab.
1. The RunLock Function must be enabled via TeleService.
2. The Bodybuilder must remove the Relay, if installed.
3. Also refer to Chapter 7.3 (
➠
Page 10).
(5)
The EM offers different configurations which can be selected upon specific request by the Customer. An overview of the available combin-
ations is listed in Chapter 7.3 - Paragraph "Compatibility between PTO and additional functions" .
