DAILY 4x4 ‒ GUIDELINES FOR BODYBUILDERS
CHASSIS INTERVENTIONS
2.12 MODIFICATIONS TO THE HEATING/CONDITIONING PLANT
29
– Printed 692.68.999 – 3 Ed. - Base 08-2020
204649
Figure 14
1. Main heater
2. Optional additional heater
3. Solenoid valve
4. Additional heater installed by body builder
A. Solenoid valve (3) open
B. Solenoid valve (3) closed
N.B. Heaters (2) and (4) may even be present on their own.
