28
DAILY 4x4 ‒ GUIDELINES FOR BODYBUILDERS
APPLICATIONS OF SUPERSTRUCTURES
3.15 SPECIAL OUTFITS
– Printed 692.68.999 – 3 Ed. - Base 08-2020
277298
Figure 18
▶ Adopt solutions which ensure the stability of the vehicle and its safety during the operation.
The bodybuilder must therefore:
● Define the type and number of stabilizers;
● provide vehicle lifting/lowering speed control on the stabilizers through appropriate flow control valves in the hydraulic sys-
tem;
● limit, as much as possible (3-5 cm), lifting of the front axle of the vehicle from the ground, compatible with the condition of
keeping the horizontal alignment.
Note
Verification of the dynamic behaviour of the vehicle complete with the superstructure is the full responsibility of the bodybuilder.
