Transmitter buttons /
receiver relays association
Receiver on DIN rail ORRD22••• (2+1 or 3 relays) :
- Transmitter buttons B1 and B2 assigned to relays R1 and R2
- "On/R3" relay set for "On" relay"
Industrial receiver (Small model)
ORRS21•••
(2 relays) :
- Transmitter buttons B1 and B2 assigned to relays R1 and R2
Industrial receiver (Small model)
ORRS42
••• (4+1 relays) :
- Transmitter buttons B1 to B4 assigned to relays R1 to R4
Industrial receiver (Large model)
ORRA82
••• (8+1 relays) :
- Transmitter buttons B1 to B8 assigned to relays R1 to R8
Industrial receiver (Large model)
ORRAH2
••• (16+1 relays) :
- Transmitter buttons B1 to B16 assigned to relays R1 to R16
(All the default assignments have been defined using the identity
code: "ON - ON - ON - ON - ON - ON - ON - ON"
Radio channel (1) Channel nb.17 (434,700 MHz)
Relay operating mode
«Continuous make contact» mode
(After having realized a transmitter button / receiver relay
association, when transmitter button is pressed, relay in the
receiver is activated, when button is no longer pressed, the relay is
deactivated)
Interlocking of conflicting
commands
No interlocking programmed
Identity code
ON - ON - ON - ON - ON - ON - ON - ON
Radio channel (1) Channel nb.17 (434,700 MHz)
"Dead man" function (2) 4 mn
ON
12345678
1.1- Delivery configuration
ORION transmitters delivery configuration :
The ORION transmitters and receivers are factory-adjusted to allow immediate use
of the product on delivery.
However, it is indispensable to customise these settings to ensure
the uniqueness of your installation and to familiarise yourself with
the complete range of functions provided by the ORION series (see
chapter 3).
ORION receivers delivery configuration :
(1) = The programming of another radio channel number can only be done with a
transmitter equipped with an "On/Off» button.
(2) = Automatic shutdown of remote control, only available with a transmitter
equipped with an "On/Off» button.
