- 8 - 324501D revision07
De















Standard
(2)
Industriel
(2)
Industriel
avec bouton
"marche/arrêt"
(
3
)
Multifonctions
(3)
Multifonctions
avec bouton
"marche/arrêt"
(
3
)
1
ORET11SL1
2
ORET21SL1 OREi21SL1 OREi22SL1
4
ORET41SL1 OREi41SL1 OREi42SL1 OREL42SL1
6
OREL62SL1
8
OREL81SL1 OREL82SL1
12
ORELD2SL1
16
ORELH1SL1
Version d'émetteur
Nombre de boutons de fonction















Rail DIN
12VDC
24VDC
24VAC
Industriel
petit modèle
12VDC
24VDC
24VAC
48VAC
Industriel
petit modèle
115VAC
Industriel
petit modèle
230VAC
Industriel
grand
modèle
12VDC
24VDC
Industriel
grand
modèle
24VAC
48VAC
Industriel
grand
modèle
115VAC
230VAC
2
ORRS21L1F ORRS21L1T ORRS21L1U
2 + 1
(5)
3
4 + 1
(5)
ORRS42L1F ORRS42L1T ORRS42L1U
8 + 1
(5)
ORRA82L14 ORRA82L1A ORRA82L1B
16 + 1
(5)
ORRAH2L14 ORRAH2L1A ORRAH2L1B
Nombre de relais de fonction
Modèle de récepteur / tension d'alimentation
ORRD22L1C
1.2- Références commerciales des produits
1.2.1- Emetteurs ORE
(1)
(1) = Livrés programmés en canal n°17 en standard. RAPPEL : le canal radio des
émetteurs peut être modifié uniquement sur les émetteurs ORE équipés du bouton
«marche/arrêt».
(2) = Livrés avec 2 piles AAA.
(3) = Livrés avec 3 piles AAA, peuvent être utilisés avec 3 accumulateurs AAA.
Ces émetteurs, lorsqu’ils sont équipés d’accumulateurs AAA, peuvent être rechargés
directement sur un support chargeur ORCL•. Le support chargeur est à commander
séparément.
(4) = Livrés programmés en canal n°17 en standard. RAPPEL : le canal radio récepteur
peut être modifié uniquement par l’utilisation d’un émetteur ORE équipé du bouton
«marche/arrêt».
(5) = Relais «marche»
1.2.2- Récepteurs ORR
(4)
