3- Product configuration
Before final installation and use, we recommend that you configure the units
with customized settings as detailed in steps 1 to 8. These steps must be
performed on an insulated work surface in the workshop.
))
))
)
3.1- Configuration steps to be respected
( ~ 10mn)
Step nb.1
Step nb.2
Step nb.3
Step nb.4
(Optional)
Step nb.5
(Optional)
Step nb.6 *
(Optional)
Step nb.8
* = Only for transmitter equipped with «On/Off» button
Step nb.7 *
(Optional)
Transmitter identity code programming procedure
> see §3.2
FAST Transmitter
button(s) / receiver relay(s)
association(s)
> see §3.3.1
Interlocking of conflicting commands programming procedure
> see §3.5
Radio channel programming procedure
> see §3.6
«Dead man» function time programming procedure
> see §3.7
Proceed to the installation on site by respecting
the installation recommendations described in §4
Operating mode programming procedure for function relays
> see §3.4
Erasing the receiver factory settings
(default settings provided on delivery)
> see §3.9
Personalized Transmitter
button(s) / receiver relay(s)
association(s)
> see §3.3.2
