standard
(ORET
)
industrial
(OREi)
multifunction
(OREL)
Housing
Housing color black yellow / black yellow
Degree of protection IP40 IP67 IP65
Weight
(
with batteries or accu.
)
65 g 75 g 160 g
Number of command
buttons
1, 2 or 4 2 or 4 4, 6, 8, 12 or 16
Power supply
3 batteries 1,5V AAA
or 3 accumulators AAA
Autonomy
Charging time
(
supplied with accus.
)
< 3 hours
Safety
Mechanical protection Built-in protected foam
Storage
Case, reference :
UBWE34
(
o
p
tional accessor
y)
Operating mode
Radio link
Transmission module (1)
Transmission frequ. (1)
Transmission power (1)
Identity code
Average range (2)
Temperature ranges
Battery or accumulator
charge level indication
Other indication
150 m in unobstructed area
50 m in typical industrial environment
ABS
2 indication levels by a red indicator light :
Red indicator light off
= batteries or accumulators charge is > 50%
Red ind. light flashes
= batteries must be replaced or accu. must be charged
Model without "On/Off" button :
A green indicator light comes on and flashes while the function button is pressed.
Model with "On/Off" button :
A green indicator light come on and flashes when the transmitter keypad is active
Momentary (when command button pressed)
256 codes, programmable by microswitches on transmitter
Operating : -20° C to + 50° C
Storage : -30° C to + 70° C
Charging (accumulator version) : 0°C to +40°C
Simultaneous commands
18 frequencies per device
UHF 433,100 MHz to 434,740 MHz - FM Modulation
2 batteries 1,5V
type AAA
< 1 mW
All versions with batteries :
1 year (used 50 times per day with impulses of 2 seconds)
Multifunction transmitters with accumulators : 42 h for 50 % use time
Case, reference :
OWE13
(optional accessory)
1 "On/Off" button (depending on model)
(1) = No licence required. Supplied programmed for channel No. 17 in standard
configuration. REMINDER : The transmitter radio channel can only be changed
on the ORE transmitters equipped with an "On/Off" button.
See Frequencies list in appendix H.
(2) = The range varies according to environment conditions, the reception antenna
and its position (the range is decreased in case of metal obstacles such as:
metal frameworks, walls etc.)
2- Technical characteristics
2.1- ORION transmitters (ORE)
