3.6- Radio channel programming procedure
REMARK : Only transmitters equipped with «On/Off» button + 2 buttons allow
the user to modify and consult the operating radio channel.
On the other transmitter models (without «On/Off» button), the radio
frequency is fixed to nb.17 - 434,700 MHz.
z A transmitter / receiver association must have been realized.
z This procedure is realized by the transmitter with buttons
B1
,
B2
and «on/off».
z The receiver will stay ON during the procedure to receive the channel modification
command.
See list of available radio frequencies (channels) in appendix H.
Requirements :
button
B1
button
B2
Va
red LED
Vb
green LED
«On/Off» button
))
))
)
button
B1
button
B2
Va
red LED
Vb
green LED
«On/Off»
button
Industrial transmitters
Multifunction transmitters
