Jay electronique ORRD22L1C - Connection to Relays; Maximum Number of Simultaneously Controlled Relays; Relay Characteristics

Gb Fr
324501D revision07 - 47 -
De
Contactor Physical unit switched by relay
Number of switching cycles for "on"
relay and function "relays"
Switching at 230VAC (70VA,cosphi=0,75)
2 x 10
6
Switching at 110VAC, (70VA,cosphi=0,75)
1 x 10
6
Switching at 48VAC (70VA,cosphi=0,75)
0,5 x 10
6
CA2DN
LC1D09
LC1D18
LC2D09
- Number of switching cycles on various contactors
2.3.2- Connection to relays
2.3.3- Relay characteristics
(«On» relay and function relays)
2.3.1- Maximum number of simultaneously controlled
relays according to industrial receiver model
))
))
)
The maximum number of relays activated at the same time is limited to :
On receivers, the connections are made on spring terminals with connection points
identified by numbers.
Flexible wires with wire section of between 0.08mm² and 2.5mm² can be used.
No common line is provided on the printed circuits (all contacts are potential-free).
-
4 for ORRS (industrial small model receiver) :
4 function relays actuated at the same time
or 3 function relays + the "On" relay activated at the same time.
-
9 for ORRA (industrial large model receiver) :
9 function relays actuated at the same time
or 8 function relays + the "On" relay activated at the same time.
• Contacts : AgNi 0,15
• Maximum power at cosphi=1 : 2000 VA
• Maximum current switching : 8 A
• Maximum voltage switching : 400 VAC
• Minimum current / voltage advised switching : 100 mA / 12 VDC
• 100 000 switching cycles at 250 VAC, 8 A, cosphi=1
• 50 000 switching cycles at 24 VDC, 8 A
• Tests per EN 60947-5-1 :
DC13 at 0,5 A / 24 VDC
AC15 at 3 A / 250VAC
