- 48 - 324501D revision07
De
Component
Characteristics of fuse and
location to be used for
ORRS Receiver
Characteristics of fuse and
location to be used for
ORRA Receiver
Board supplied with
12 VDC
250 mA / 250 VAC / T -
F2
315 mA / 250 VAC / T -
F2
Board supplied with
24 VDC
500 mA / 250 VAC / T -
F1
250 mA / 250 VAC / T -
F1
Board supplied with
24 VAC
500 mA / 250 VAC / T -
F1
1,6 A / 250 VAC / T -
F2
Board supplied with
48 VAC
500 mA / 250 VAC / T -
F1
800 mA / 250 VAC / T -
F1
Board supplied with
115VAC
100 mA / 250 VAC / T -
F1
315 mA / 250 VAC / T -
F2
Board supplied with
230VAC
62 mA / 250 VAC / T -
F1
160 mA / 250 VAC / T -
F1
- Function relays
- "On" relay
No protection No protection
• Against overcurrents : 1 fuse on phase (ORRS and ORRA).
• Against polarity inversions in the case of 12VDC power supply.
- Protection of power supply
- Fuse characteristics
Industrial receiver
«small model»
ORRS
Industrial receiver
«large model»
ORRA
R1 R2 R3 R4 R5 R6
R
R13 R14 R15
123
30 31 32 33 34
3
5
45678910111213 1516171814
RM
F1
F2
2.3.4- Protection of receiver board and relays
R1 R2 R3RM R4
123 45678910111213
V1 V2 V3
JP1 JP2 JP3
F1
F2
