324501D revision07 - 43 -
De
Reference Description
OWR01
BNC plug-in antenna kit
(see installation kit in appendix E) (2)
OWR02
Internal antenna kit
(see installation kit in appendix F) (3)
VUB084
1/4 wave antenna straight, band BNC
(4)
VUB086
1/2 wave antenna straight, band BNC
(4)
VUB060
90 ° BNC elbow for antenna VUB084 or BNC antenna extension
(4) (5)
VUB170
0,5m extension for BNC antenna
(4)
VUB105
2m extension for BNC antenna + non insulated bracket
(4)
VUB125
5m extension for BNC antenna + non insulated bracket
(4)
VUB131
10m extension for BNC antenna + non insulated bracket
(4)
Reference Description
OWE10
Carrying clip (on support UBWE01, belt, pocket ..)
(see installation in appendix G) (1)
OWE20
Neck strap
OWE13
Case for standard (ORET) or industrial (OREi) transmitter
UBWE34
Case for multifunction (OREL) transmitter
OWE01
Mounting support for standard and industrial transmitter with carrying clip
ORCL
Mounting support for multifunction transmitter
ORCL1
12-24 VDC (vehicle connector) / 9 VDC charger support unit + 3 accumulators AAA type, for
multifunction transmitters
(
OREL
)
with accumulators
ORCLU
230 VAC (european plug) / 9 VDC charger support unit + 3 accumulators AAA type, for multifunction
transmitters
(
OREL
)
with accumulators
ORCLW
230 VAC (english plug) / 9 VDC charger support unit + 3 accumulators AAA type, for multifunction
transmitters
(
OREL
)
with accumulators
OWE301
45 black/white rectangular function labels for standard, industrial and multifunction
transmitters (4, 6 or 8 buttons)
(1)
OWE403
64 black/white round labels for multifunction transmitters (12 or 16 buttons)
(1)
(2) = BNC antenna and BNC extension to be ordered separately.
(3) = 1 kit is supplied with industrial receivers.
(4) = Except for the DIN rail model which comes with a BNC antenna connector as
a standard feature, the other receiver models require the plug-in antenna kit
OWR01 for use of an antenna or a plug-in antenna extension.
(5) = Not suitable for direct connection to antenna VUB086 ; in this case, use an
intermediate extension type VUB1··.
1.2.3- Transmitter accessories
1.2.4- receiver accessories
(1) = 1 kit is supplied with transmitter
