blinks 2 times
and goes off,
relay(s) controlled by the button is/are on
"BISTABLE" (ON/OFF) mode
blinks 1 time and goes off, relay is activated,
relay(s) controlled by the button is/are on
"Continuous break contact" mode
blinks 1 time and goes off, relay is deactivated,
relay(s) controlled by the button is/are on
"Continuous make contact" mode
Relay operating mode
programming start
Maintained pressure on the button (2 seconds)
Maintained pressure on the button (2 seconds)
Maintained pressure on the button (2 seconds)
V2
V2
V2
3- "Industrial" type receivers (ORRA and ORRS): switch ON receivers.
4- -
V2
and
V3
LEDs blink 3 times then go off.
5- Press and maintain the pressure (approximately 2 seconds) before releasing
the transmitter button wich associated relays must have a personalized operating
mode.
Each maintained pressure (2 seconds) then loosened on the button will change
the current operating mode of associated relay(s),
V2
indicates the current
mode:
6- Once the programming procedure is finished, switch off industrial receiver (ORRS
and ORRA) and remove jumper
JP2
, or set the
JP2
microswitch to the
"OFF" position (ORRD).
Remark :
If the pressure on the transmitter button is not maintained for a long time
(approximately 2 seconds) before being loosened,
V3
remains switched
on, indicating that the order of modification did not correctly take place.
