Section 2 DBV® Series DBV-400 Banknote Validator Installation
Standard Interface Circuit Schematics (Continued 3)
Figure 2-14 illustrates the DBV-400 ID-002 Pulse Interface Schematic Diagram.
Figure 2-14 DBV-400 ID-002 Pulse Interface Schematic Diagram
Figure 2-14 DBV-400 ID-002 Pulse Interface Schematic Diagram
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
IN12V-24V
GND
IN12V-24V
GND
GND
D/E
BUSY
ABN
IN12V-24V
GND
IN12V-24V
GND
GND
D/E
BUSY
ABN
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Power
Power
INLINE1
5V
10k
100P
5V
Sleep Control
CONTROLLER SIDE
DBV-400 SIDE
